| Year | 2022 |
|---|---|
| Make | Makino |
| Model | U6 H.E.A.T. |
Description |
EDM Wire |
| Reference # | 8074620 |
|
This machine has been recently sold. If you are interested in a similar machine, We will be happy to locate one for you. |
|
Used Makino U6 H.E.A.T. (2022) CNC EDM for Sale. This pre-owned Makino CNC EDM wire is located in The United States and available to be seen under power for an inspection. If you have any questions regarding this Makino EDM, please feel free to contact us. You may Activate Pricing to view the price of this CNC Machine, or request a quote by clicking on the Inquire Now button.
Specifications
| X-Axis Travel |
25.59" |
|---|---|
| Y-Axis Travel |
17.71" |
| Z-Axis Travel |
16.53" |
| Control |
Hyper I |
| U/V Axis Travel |
2.95" x 2.95" |
| Degree Taper Cutting |
15 @ 4" |
| Inside Tank Dimensions |
42.13" x 34.65" |
| Rapid Traverse (X/Y/Z) |
78.74 IPM |
| Wire Electrode Size Range |
0.07, 0.10, 0.15, 0.20, 0.25, 0.30 mm |
| X/Y-Axes (Full Stroke) Repeatability |
+/- 0.000039" |
| Max Load on Table |
3,968 Lbs |
| Machine Weight |
13,007 Lbs |
| Power Requirement |
208/3/60 |
Features
|
Dielectric Chiller Unit |
Direct Drive PWM Digital AC Servo |
|
Power Supply |
Auto Wire Threading |
|
Chiller |
Low Hours |
|
Wire Chopper |
Multi-Tap Transformer |
