| Year | 2018 |
|---|---|
| Make | Trumpf |
| Model | TruBend 5320 |
Description |
350 Ton x 14' Hydraulic Press Brake |
| Reference # | 8073662 |
Used Trumpf TruBend 5320 (2018) CNC Press Brake for Sale. This pre-owned Trumpf CNC press brake is located in The United States. If you have any questions regarding this Trumpf Press Brake, please feel free to contact us. You may Activate Pricing to view the price of this CNC Machine, or request a quote by clicking on the Inquire Now button.
Specifications
| Capacity |
350 Ton |
|---|---|
| Overall Length of Bed |
14' |
| Control |
Trumpf Siemens |
| Distance Between Housings |
144" |
| Stroke |
17.51" |
| Throat Depth |
16.53" |
| Open Height |
24.21" |
| Y-Axis Rapid |
520 IPM |
| Y-Axis Working |
59 IPM |
| Y-Axis Traverse Speed |
520 IPM |
| X-Axis |
2,362 IPM |
| R-Axis |
780 IPM |
| Z-Axis |
4,132 IPM |
| Dimensions |
204" x 81" x 126"H |
| Weight |
51,588 Lbs |
Features
|
ACB (Automatically Controlled Bending) |
Bed Extension |
|
Bending Aid |
Hydraulic Upper and Lower Clamping |
|
CNC Crowning |
Laser Safe |
|
6-Axis Back Gauge |
Tooling Included |
|
Work Area Lighting |
*
