| Year | 2016 |
|---|---|
| Make | Faccin |
| Model | 4HEL-3146 |
Description |
Four Roll Plate Roll |
| Reference # | 8073034 |
Faccin 4HEL-3146
Specifications
| Maximum Plate Width |
120" |
|---|---|
| Top Roll Diameter |
18.11" |
| Lower Roll Diameter |
16.93" |
| Side Rolls Diameter |
13.39" |
| Bending Force on Top Roll |
441 Ton |
| Infinitely Variable Rotation Speed |
25 FPM |
| Rolling Power |
60 HP |
| Full-Length Capacity At 37.7 KSI |
1.42" Bending Thickness With 90.5" Inside Dia. / 1.18" Pre-Bend Thickness With 90.5" Inside Dia |
| Full-Length Capacity At 52.2 KSI |
1.22" Bending Thickness With 90.5" Inside Dia. / 0.95" Pre-Bend Thickness With 90.5" Inside Dia |
| Dimensions |
252" X 85" X 105" |
| Weight |
59,500 Lbs |
Features
|
4 Axis Clamping for Side Support |
4 Bearings Supporting Each Roll |
|
Air-Oil Exchanger Upgrade |
Centralized Pump Lubrication System |
|
Cone Bending with Electronic Control |
Designed to Accept Future Upgrades |
|
Dual Linear Slide Sys for Rolls Translation |
Electronic Balancing System for Roll Synch |
|
Extra Torque & Special Braking Power System |
Extra-Large Double Shaft Drop End |
|
Hardened & Polished Rolls |
High Precision and Productivity Package |
|
Linear Slides |
Micro-Positioning |
|
Pressure Gauges for Pinch Roll Monitoring |
Side Support |
|
Safety Barrier with Emergency Stop |
Siemens Pgs-Ultra CNC |
|
Simultaneous Machine Movements |
Top Roll Tilting with Hydraulic Drop End Opening |
|
Ultra-Wide Roll Bearing Housings |
Overhead Support |
