| Year | 2012 |
|---|---|
| Make | Peddinghaus |
| Model | Ocean Avenger MDL-1000B |
Description |
CNC Beam Drill Line |
| Reference # | 8075946 |
Peddinghaus Ocean Avenger MDL-1000/1B
Specifications
| Control |
Siemens 840D CNC |
|---|---|
| Min/Max Drill Diameter |
1/4" - 2" |
| Stroke |
13" |
| Max X/Y-Axis Speed |
120 FPM |
| Max Beam Capacity |
40" x 60' |
| Material Thickness |
1-1/4" |
| Max Thickness |
10" |
| Spindle Motor |
20 HP |
Features
|
Drill Sharpener |
*
Important: All machinery specifications must be independently verified by buyer. All machinery sales are
subject to prior sale. Any agreement to purchase or sell machinery must be in writing.
